Desaturate  Method

Description         This method will desaturate the image. This function works for only 24 bit per pixel images.

Examples

color                                                           desaturated

The original 900 x 1300 sized color image and desaturated image.

Syntax                 RetVal = [BIIMAGE.]Desaturate  iShowProgress hWnd

Returns               RetVal                    LONGLONG The handle of new DIB, 0 if an error occurred.

Remarks             hDib                       LONGLONG Handle of the source image.

                            iShowProgress       Long                This parameter specifies the displaying of the progressbar and the preview dialog.

Available values:

DISPLAY_NONE (0) - The progressbar and the preview dialog will not display before filtering.

DISPLAY_PROGRESS (1) - The progressbar will display during filtering procedure.

DISPLAY_DIALOG (2) - The preview dialog will display before filtering. This dialog shows the part of the image before and after filtering.

DISPLAY_BOTH (3) - The progressbar and the preview dialog will display.

IMPORTANT: The preview dialog will only display, if there is BIDlgs32.dll installed.

                            hParent                  LONGLONG Handler of the parent window to display preview dialog.



The method will not free the input DIB.
