Description This method will modify the CMYK levels of the image. This function works for only 24 bit per pixel images.
Examples
The original 900 x 1300 sized color image and the filtered image with cyan = -80, magenta = -7, yellow = 19 and black = -39 parameter values.
Syntax RetVal = [BIIMAGE.]ColorCMYKLevels hDib cyan magenta yellow black iShowProgress hWnd
Returns RetVal LONGLONG The handle of new DIB, 0 if an error occurred.
Remarks hDib LONGLONG Handle of the source image.
cyan short The method increases with “cyan” percents the cyan values of the pixels [-100 - 100].
magenta short The method increases with “magenta” percents the magenta values of the pixels [-100 - 100].
yellow short The method increases with “magenta” percents the magenta values of the pixels [-100 - 100].
black short The method increases with “black” percents the black values of the pixels [-100 - 100].
iShowProgress Long This parameter specifies the displaying of the progressbar and the preview dialog.
Available values:
DISPLAY_NONE (0) - The progressbar and the preview dialog will not display before filtering.
DISPLAY_PROGRESS (1) - The progressbar will display during filtering procedure.
DISPLAY_DIALOG (2) - The preview dialog will display before filtering. This dialog shows the part of the image before and after filtering.
DISPLAY_BOTH (3) - The progressbar and the preview dialog will display.
IMPORTANT: The preview dialog will only display, if there is BIDlgs32.dll installed.
hParent LONGLONG Handler of the parent window to display preview dialog.
The method will not free the input DIB.
