The original 900 x 1300 sized color image and the Hue/Saturation/Intensity operated image with Hue = 45, Saturation = -16, Intensity = 61, Min = 0 and Max = 360 parameter values.
#include "BIIMAGE.H"
HDIB CALLBACK ColorHueSaturation( HDIB HDib,
int hue,
int saturation,
int intensity,
UINT min,
UINT max,
int iShowProgress,
HWND hParent)
Description
This function will modify the hue, intensity and saturation values of the image. This function works for only 24 bit per pixel images.
Examples
The original 900 x 1300 sized color image and the Hue/Saturation/Intensity operated image with Hue = 45, Saturation = -16, Intensity = 61, Min = 0 and Max = 360 parameter values.
Parameters
|
HDIB |
hDIB |
Handle of the source DIB. |
|
int |
hue |
Value of hue [-180 - 180]. |
|
int |
saturation |
Value of saturation [-255 - 255]. |
|
int |
intensity |
Value of intensity [-255 - 255]. |
|
UINT |
min |
The minimum value of the range of hue [0 - 360]. |
|
UINT |
max |
The maximum value of the range of hue [0 - 360]. |
|
int |
iShowProgress |
This parameter specifies the displaying of the progressbar and the preview dialog. Available values: DISPLAY_NONE (0) - The progressbar and the preview dialog will not display before filtering. DISPLAY_PROGRESS (1)-The progressbar will display during filtering procedure. DISPLAY_DIALOG (2) - The preview dialog will display before filtering. This dialog shows the part of the image before and after filtering. DISPLAY_BOTH (3) - The progressbar and the preview dialog will display. IMPORTANT: The preview dialog will only display, if there is BiDlgs.dll installed. |
|
HWND |
hParent |
Handler of the parent window to display preview dialog. |
Return values
The handle of the new filtered DIB or NULL if an error occurred. The GetLastColorConvertError function will return the error code.
Programming notes
The function will not free the input DIB.
Rules:
If min < 0 or min > 360 or max < 0 or max > 360 or min = max the function returns NULL, and the error code will be CCINVALIDPARAMETER.
If min < max, the range of hue will be [min, max],
If min > max, the range of hue will be [0, max] and [min, 360].
If min = max = 0, the intervallum will be [0, 360].
